Hi,
- I use Epson TM-U220B plugged via USB. I installed POS printer server.
On receipt printed, Total, Grand total, Paid amount, …etc are written in line break. Every amount is in new line on the paper. So receipt printer prints a long receipt. See attachment.
- Receipt have strange characters in top of the paper. Characters looks like this.
?ˆ9LìÒ™ÈsbgÙ®|Èl!õùUSh9i°bžr:"y_dlÀóD›¿ý|-NœÈR"4ø2ÏGÇ% õZ´4ñËyÄ7 ëÈðÉ‚‹ ¨Þ ÿÿ PK ! ƒ Æ ‡ xl/workbook.xml¤UÛnâ0}_iÿÁò;Í…&[¢†ª@«VjWh·—¤Ê8†X8vÖv
ݪÿ¾ã„P./Ý6;Î 'çxΘӳU!Ð3Ó†+™âàÈLjIª2.ç)¾¿»ìœd,‘J²¿0ƒÏúß¿.•^L•Z &Źµeây†æ¬ æH•LBd¦tA,,õÜ3¥f$39c¶^èû±W.qƒè¨ÙŒS6R´*˜´
ˆf‚X or^š +ˆ^Te‡ª¢ˆ)Ü¾Ô 4¹žK¥ÉT€ìU¡•†O ßÀ‡!lß¡ƒWœjeÔÌ ´×>Ð ø^ìlÁêp>†tìiöÌ]
7¬tüIVñ+~ ü/£Ú+ lÞ'Ñ¢ ·÷Og\°‡Æºˆ”åOR¸J Œ1ö"ã–e)þKµd;tU*. v£®½þÆÎc26#•°wä :#Ž{aä2ÁçÂ2-‰eC%-øpë«ž«±‡¹‡£_ìOÅ5ƒÆV MÈÔŒ‰ÍQ¥EŠ‡ÉäÞ€üÉßœ3©¥
Thanks
- MSAnswered
Hello,
Please edit your printer and reduce the
characters per lineYou will need to restart the POS Server after editing the printer.Can you please take the photo of strange characters too.
Thank you
- GMAnswered
Hello,
I encoutered this issue 3 weeks ago. i didn’t keep paper with me but to solve this strange characters:
-
i deleted my logo or SMA logo from the receipt printer in SMA settings and replaced with white logo of 300*80px, then all strange characters were replaced by “||”.
-
To solve Break line, I add shared printer type “Windows” in settings, then i POS settings, i chose "PHP Server(only for local installation). So i didn’t used “PHP POS Printer server app” because roll paper become too long
-
- MSAnswered
Hello,
I find that the character set for prints are causing the issue. My test printer codepage is set to Chinese characters and it print Thai & Arabic in Chinese chars 😦 I am check if I could add option to set the code page.
Thank you
- MSAnswered
Hello,
Can you please help me check with this installer https://1drv.ms/u/s!AgnnTuY8C10ggfNtbv2cbz5MrXUPeA?e=wHjhiz
Thank you
